One Year Warranty
4 Way Air Deflection
Inverter Compatible
Low Noise
Product Specifications Mode of Operation Manual Water Tank capacity ( Litres aupto Brim ) 100 L Cooling Medium Honeycomb pads ( Brown colour, Grade- 7090, Odour Free ) Air Delivery ( Cu.M/Hr ) 4000-4200 CMH Air Throw Distance 40 Ft Features Auto Fill Yes Water Overflow Yes Easy Draining of water Yes Water level Indicator Yes 3 Speed Control H,M,L Blower/ Fan type 16" ABS Plastic Fan Blade Castor / Trolley 4 Castor Prevents Mosquitoe Breeding No Dust Filter No Ice chamber Yes Vertical louver Movement Motorized Horizontal Louver Movement Manual Light and Logo Yes Motor Mounting On Mounting Bracket Technical Specifications Rated voltage 230V , 50 Hz Power Consumption ( Wattage ) 190 Watts Current ( Ampere ) 1.0 Amp RMP of Fan Blade 1350 RPM RMP Difference ( H-M/ M-L ) 80-100 RPM Peak Air Velocity 10.0 m/s Avg Peak Air Velocity 9.5 m/s TR of Motor at 250V/50Hz, High Speed Below 70° C TR of Motor at 270V/50Hz, High Speed Below 80° C TR of Motor at 180V/50Hz, Low Speed Below 70° C Leakage Test No water leakage from Tank or any other cooler parts. Electrical Test Leakage Current Leakage Current not more than > 0.21 mA Insulation Resistance IR > 5 M Ω High Voltage At 1500 V AC between Live Part & Body Starting of Motor Motor start at 0.85 times at rated Voltage Endurance Test For 96 Hrs, At 1.15 times of rated voltage , Running OK Drop Test Distance-1 meter
Drop box from 8 different side's.Box should not tear &Check cooler all Assembly should be properNoise Test 68-70 Db along with ambient 45Db. Checked with DB meter Vibration Test No cooler Vibration Water Distribution on Pads Water Distribution is uniform on all 3 side Honeycomb Pads Wetting of Honeycomb Pads Wetting is proper Cooler Movement Movement is OK along with Tank full of water, moving about 1 km on rough surface. Body Material ( Front ) ABS Material ( Side ) PP Material ( Back ) PP Material ( Top ) ABS Material ( Control Panel ) ABS Material ( Tank ) PPTF Material ( Knob ) ABS Material ( Louvers ) ABS
